| Engine Model | 4D34i |
| Maximum Power – (kW) | 125kW @ 2500 rpm |
| Maximum Torque – (Nm) | 520Nm @ 1500 rpm |
| No. of Cylinders, cc | 4, 3907 |
| Emission Standard | Bharat Stage VI – OBD-2 |
| Gear Box Model & Type | Improved G85, 6F+1R, Mechanical, Synchromesh Gears |
| Clutch Type | Single Dry Plate, Hydraulic Control |
| Clutch Dia, Wear (mm) | 362, 3.6 |
| Power Take Off | Standard |
| Front Axle | IF 5.0 |
| Rear Axle | DANA S 145 |
| Rear Axle Ratio | 6.33 |
| Frame Section (D x W x T) (mm) | 230 x 80 x 7 |
| Front Suspension | Semi elliptic leaf spring with hydraulic shock absorbers |
| Rear Suspension | Semi elliptic laminated leaf spring |
| Anti-Roll Bar | Front: Standard Rear: Standard |
| Service Brake | Pneumatic, Foot Operated, Dual Line with ABS |
| Parking Brake | Spring Actuated with Hand Brake Valve @ Cab |
| Front Brake Size (mm) & Type | Ø 360 drum |
| Rear Brake Size (mm) & Type | Ø 360 drum |
| Cabin | Day Cabin |
| Steering Type | Hydraulic Power Assisted |
| Battery Capacity | 75Ah |
| Voltage | 24V |
| Pattern & Size | Nylon Tyre – 8.25×20 |
| Gross Vehicle Weight – (kg) | 13000 kgs |
| Wheel Base (mm): | 3160 | ||
| Loading Span (ft) / Loadbody cpc (Cu.m): | 6.5 Cum | ||
| Overall Length (mm): | 5435 | ||
| Overall Width (mm): | 2135 | ||
| Overall Height (mm) (CBC): | 2420 | ||
| Front Overhang (mm): | 1275 | ||
| Rear Overhang (mm): | 1000 | ||
| Ground Clearance (mm): | 245 |
| Filling Capacity (L) | 171L/ 160L |
| Adblue Tank / Filling Capacity (L) | 43L/ 36L |
| Maximum Gradeability (%) | 38.70% |
| Maximum Geared Speed (kmph) | 60 kmph |
Unlock exclusive offers on the 1217C! Get special discounts, financing options, and exchange benefits. Click the button below to inquire now—our team will get back to you shortly!
Features like Driver Attention Monitoring, air-suspended seats, and advanced braking systems.
Tested across Indian terrains for superior durability and performance.
