| Engine Model | 4D34i |
| Maximum Power – (kW) | 125 kW @ 2500 rpm |
| Maximum Torque – (Nm) | 520 Nm @ 1200 – 1600 rpm |
| No. of Cylinders, cc | 4, 3900 |
| Emission Standard | Bharat Stage VI – OBD-2 |
| Gear Box Model & Type | Improved G85, 6F+1R, Mechanical, Synchromesh Gears |
| Clutch Type | Single Dry Plate, Hydraulic Actuated |
| Clutch Dia, Wear (mm) | 362, 3.6 |
| Power Take Off | Auxiliary Fitment |
| Front Axle | IF 5 |
| Rear Axle | DANA S 145 |
| Rear Axle Ratio | 4.56 (S), 6.33 (O) |
| Frame Section (D x W x T) (mm) | 228 x 80 x 6 |
| Front Suspension | Multileaf Spring |
| Rear Suspension | Multileaf Spring |
| Anti-Roll Bar | Front Standard, Rear Optional |
| Service Brake | Pneumatic, Foot Operated, Dual Line Non – ABS |
| Parking Brake | Spring Actuated with Hand Brake Valve @ Cab |
| Front Brake Size (mm) & Type | Ø 360 drum |
| Rear Brake Size (mm) & Type | Ø 360 drum |
| Cabin | Day Cabin |
| Steering Type | Hydraulic Power Assisted |
| Battery Capacity | 75Ah |
| Voltage | 24V |
| Pattern & Size | Radial tyres – 8.25R20 Tubeless tyres – 255/70R22.5 |
| Gross Vehicle Weight – (kg) | 11990 kgs |
| Wheel Base (mm): | 3360 | 3760 | 4250 | 4800 | 5050 |
| Loading Span (mm): | 4580 | 5275 | 6230 | 6780 | 7495 |
| Overall Length (mm): | 6380 | 7075 | 8030 | 8580 | 9295 |
| Overall Width (mm): | 2420 | 2420 | 2420 | 2420 | 2420 |
| Overall Height (mm) (CBC): | 2500 | 2500 | 2500 | 2500 | 2500 |
| Front Overhang (mm): | 1275 | 1275 | 1275 | 1275 | 1275 |
| Rear Overhang (mm): | 1745 | 2040 | 2505 | 2505 | 2970 |
| Ground Clearance (mm): | 245 | 245 | 245 | 245 | 245 |
| Fuel Tank / Filling Capacity (L) | 171L/160L | 215L/200L | 215L/200L | 215L/200L | 215L/200L |
| Adblue Tank / Filling Capacity (L) | 43L/36L | 43L/36L | 43L/36L | 43L/36L | 43L/36L |
| TCD (m) | 13.9m | 14.8m | 16.7m | 18.7m | 19.7m |
| Maximum Gradeability (%) | 6.33 RAR – 44.2% ; 4.56 RAR – 30.2% |
| Maximum Geared Speed (kmph) | 80 kmph | 80 kmph | 80 kmph | 80 kmph | 80 kmph |
Unlock exclusive offers on the 1217R! Get special discounts, financing options, and exchange benefits. Click the button below to inquire now—our team will get back to you shortly!
Features like Driver Attention Monitoring, air-suspended seats, and advanced braking systems.
Tested across Indian terrains for superior durability and performance.
