| Engine Model | 4D34i |
| Maximum Power – (kW) | 125 kW @ 2500 rpm |
| Maximum Torque – (Nm) | 520 Nm @ 1200 – 1600 rpm |
| No. of Cylinders, cc | 4, 3900 |
| Emission Standard | Bharat Stage VI – OBD-2 |
| Gear Box Model & Type | Improved G85, 6F+1R, Mechanical, Synchromesh Gears |
| Clutch Type | Single Dry Plate, Hydraulic Actuated |
| Clutch Dia, Wear (mm) | 362, 3.6 |
| Power Take Off | Optional |
| Front Axle | IF 5 |
| Rear Axle | DANA S 145 |
| Rear Axle Ratio | 4.56 (S), 6.33 (O) |
| Frame Section (D x W x T) (mm) | 228 x 80 x 6 |
| Front Suspension | Multileaf Spring |
| Rear Suspension | Multileaf Spring |
| Anti-Roll Bar | Front Standard, Rear Optional |
| Service Brake | Pneumatic, Foot Operated, Dual Line with ABS |
| Parking Brake | Spring Actuated with Hand Brake Valve @ Cab |
| Front Brake Size (mm) & Type | Ø 360 drum |
| Rear Brake Size (mm) & Type | Ø 360 drum |
| Cabin | Day Cabin |
| Steering Type | Hydraulic Power Assisted |
| Battery Capacity | 75Ah/100Ah(HAP) |
| Voltage | 24V |
| Pattern & Size | Radial tyres – 8.25R20 |
| Gross Vehicle Weight – (kg) | 13000 kgs |
| Wheel Base (mm): | 3360 | 3760 | 4250 | 4800 | 5050 |
| Loading Span (mm): | 4580 | 5275 | 6230 | 6780 | 7495 |
| Overall Length (mm): | 6380 | 7075 | 8030 | 8580 | 9295 |
| Overall Width (mm): | 2420 | 2420 | 2420 | 2420 | 2420 |
| Overall Height (mm) (CBC): | 2500 | 2500 | 2500 | 2500 | 2500 |
| Front Overhang (mm): | 1275 | 1275 | 1275 | 1275 | 1275 |
| Rear Overhang (mm): | |||||
| Ground Clearance (mm): | 245 | 245 | 245 | 245 | 245 |
| Fuel Tank / Filling Capacity (L) | 215L/200L | For 3360 – 171L/160L |
| Adblue Tank / Filling Capacity (L) | 43L/36L | 43L/36L | 43L/36L | 43L/36L | 43L/36L |
| TCD (m) | 13.9m | 14.8m | 16.7m | 18.7m | 19.7m |
| Maximum Gradeability (%) | 6.33 RAR – 39.2% ; 4.56 RAR – 27% |
| Maximum Geared Speed (kmph) | 70 kmph | 70 kmph | 70 kmph | 70 kmph | 70 kmph |
