| Engine Model | OM 926 |
| Maximum Power – (kW) | 191kW @ 2200 rpm |
| Maximum Torque – (Nm) | 900Nm @ 1200 – 1600 rpm |
| No. of Cylinders, cc | 6, 7200 |
| Emission Standard | Bharat Stage VI – OBD-2 |
| Gear Box Model & Type | Improved G85, 6F+1R, Mechanical, Synchromesh Gears ; G131, 9F+1R, Mechanical Synchromesh Gears |
| Clutch Type | Single Dry Plate, Hydraulic Control |
| Clutch Dia, Wear (mm) | 395, 3.5 |
| Power Take Off | Standard |
| Gear Box Model & Type | Improved G85, 6F+1R, Mechanical, Synchromesh Gears ; G131, 9F+1R, Mechanical Synchromesh Gears |
| Clutch Type | Single Dry Plate, Hydraulic Control |
| Clutch Dia, Wear (mm) | 395, 3.5 |
| Power Take Off | Standard |
| Frame Section (D x W x T) (mm) | 288 x 70 x 9 |
| Front Suspension | Parabolic Type Leaf Spring with 2 Hydraulic Shock Absorbers |
| Rear Suspension | Semi-Elliptical Leaf Spring |
| Anti-Roll Bar | Front: Standard Rear: Standard |
| Service Brake | Pneumatic Foot Operated, Dual Line with ABS |
| Parking Brake | Pneumatically Operated Hand Control Valve |
| Front Brake Size (mm) & Type | Ø 410 drum |
| Rear Brake Size (mm) & Type | Ø 410 drum |
| Cabin | Day Cabin |
| Steering Type | Hydraulic Power Assisted |
| Battery Capacity | 120Ah |
| Voltage | 24V |
| Pattern & Size | Radial Tyres (11R20) Nylon Tyre (11×20) |
| Gross Vehicle Weight – (kg) | 18500 kgs |
| Wheel Base (mm): | 3600 | ||
| Loading Span (ft) / Loadbody cpc (Cu.m): | 10.5 Cu.m Box | ||
| Overall Length (mm): | 6185 | ||
| Overall Width (mm): | 2490 | ||
| Overall Height (mm) (CBC): | 2960 | ||
| Front Overhang (mm): | 1485 | ||
| Rear Overhang (mm): | 1100 | ||
| Ground Clearance (mm): | 265 |
| Filling Capacity (L) | 260L/200L |
| Adblue Tank / Filling Capacity (L) | 43L/ 36L |
| TCD (m) | 13.5 m |
| Maximum Gradeability (%) | 41%(G85) / 53.9%(G131) |
| Maximum Geared Speed (kmph) | 60 kmph |
Unlock exclusive offers on the 1926C! Get special discounts, financing options, and exchange benefits. Click the button below to inquire now—our team will get back to you shortly!
Features like Driver Attention Monitoring, air-suspended seats, and advanced braking systems.
Tested across Indian terrains for superior durability and performance.
